- General Information
- Manufacturer
- U.S. Robotics
- Manufacturer Website Address
- http://www.usr.com
- Brand Name
- USRobotics
- Product Line
- Courier
- Product Type
- Modem/Wireless Router
USR® Cellular M2M Gateway provides LAN-to-WWAN routing ideal for traditional M2M and IoT applications around the world.
The new USR® Courier® M2M 4G LTE Cat 1 Cellular Gateway provides cost-effective LAN-to-WWAN small-volume data transfer on all major 4G cellular networks. Affordable Cat 1 hardware reduces overall costs significantly while lowering the entry barriers to a wide range of M2M solutions making for an easier transition from analog to a long-term cellular solution. With an embedded serial port, the gateway allows quick implementation for a wide variety of serial-based systems already out in the field - making it ideal for M2M Serial applications including remote maintenance and control, Point-of-Sale, ATMs, monitoring, and automation. The embedded HTML-based GUI makes initial configuration simple and fast, with remote configuration available after deployment. For reliable, secure persistent connections rely on USR's international cellular modems and gateways for mission-critical applications.
- Warranty
- Limited Warranty
- 2 Year
- Wireless Specifications
- Broadband Transmission Technology
- Cellular
- Ethernet
- Cellular Generation
- 4G
- Cellular Network Supported
- LTE 1900
- LTE 1700
- LTE 850
- LTE 700
- WCDMA 1900
- WCDMA 850
- Cellular Data Connectivity Technology
- HSDPA
- HSUPA
- LTE
- Number of External Antennas
- 2
- Interfaces/Ports
- Number of Network (RJ-45) Ports
- 1
- Number of Broadband (RJ-45) Ports
- 1
- Network & Communication
- Ethernet Technology
- Fast Ethernet
- VPN Supported
- Yes
- Multi-SIM Supported
- No
- Number of SIM Card Supported
- 1
- Physical Characteristics
- Form Factor
- DIN Rail Mountable
- Height
- 1"
- Width
- 5.9"
- Depth
- 4.5"
- Weight (Approximate)
- 15.17 oz
- Miscellaneous
- Package Contents
- Courier M2M 4G LTE CAT 1 Cellular Gateway
- 2 x 0db SMA Penta-band Antennas
- Ethernet Cable
- US Power Supply
- Quick Start Guide
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Country of Origin
- Taiwan
