- General Information
- Manufacturer
- Vertiv
- Manufacturer Website Address
- http://www.vertiv.com/
- Brand Name
- Geist
- Product Type
- PDU
I10005L provides reliable power distribution where you need it in the rack. With the Geist Upgradeable hot-swap technology, users may easily transform basic PDUs to metered or monitored PDUs with the addition of the appropriate Interchangeable Monitoring Device (IMD) module; all without causing any interruption.
- Warranty
- Limited Warranty
- 5 Year
- Technical Information
- PDU Type
- Basic
- Phase
- Three Phase
- Plug/Connector Type
- NEMA L21-20P
- Plug/Connector Detail
- 1 x NEMA L21-20P
- Receptacle Type
- U-Lock IEC 60320 C13
- U-Lock IEC 60320 C19
- NEMA 5-20R
- Receptacle Detail
- 33 x U-Lock IEC 60320 C13
- 6 x U-Lock IEC 60320 C19
- 2 x NEMA 5-20R
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Input Voltage Range
- 120 V AC - 208 V AC
- Output Voltage
- 208 V AC
- Power Rating (Watt)
- 5700 W
- Input Current
- 20 A
- Physical Characteristics
- Mounting Orientation
- Vertical
- Mount Type
- Rack-mountable
- Rack Height
- 0U
- Width
- 2"
- Depth
- 2"
- Length
- 72"
- Miscellaneous
- Package Contents
- MN01X4W0-41ML59-2TL21A0A10-S 41-Outlets PDU
- Vertical Mounting Bracket Kit
- Country of Origin
- United States
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
