- General Information
- Manufacturer
- Supermicro Computer, Inc
- Manufacturer Website Address
- http://www.supermicro.com
- Brand Name
- Supermicro
- Packaged Quantity
- 1
- Package Type
- Bulk
- Product Type
- Desktop Motherboard
- Processor & Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- W480E
- Total Processor Supported
- 1
- Processor Socket
- Socket LGA-1200
- Processor Supported
- Xeon
- Core i3
- Core i5
- Core i7
- Core i9
- Celeron
- Pentium
- Memory
- Number of Memory Slots
- 4
- Memory Form Factor
- DIMM
- UDIMM
- Maximum Memory Supported
- 128 GB
- Memory Technology
- DDR4 SDRAM
- Memory Speed Supported
- 2933 MHz
- 2666 MHz
- 2400 MHz
- 2133 MHz
- I/O Controller
- Controller Type
- Serial ATA/600
- RAID Supported
- Yes
- RAID Levels
- 0
- 1
- 5
- 10
- Video
- Onboard Video
- On-board Video Chipset
- Graphics Controller Model
- AST2500
- Audio
- Audio Channels
- 7.1
- Network & Communication
- Gigabit Ethernet
- Yes
- 10Gigabit Ethernet
- Yes
- I/O Expansions
- Total Number of Expansion Slots
- 3
- Total Number of PCI Express Slots
- 3
- Number of PCI Express x4 Slots
- 1
- Number of PCI Express x8 Slots
- 1
- Number of PCI Express x16 Slots
- 1
- Interfaces/Ports
- Total Number of USB Ports
- 4
- Number of USB 3.2 Ports
- 4
- VGA
- Yes
- DisplayPort
- Yes
- DVI
- Yes
- Number of Network (RJ-45) Ports
- 4
- Onboard Interfaces
- Number of SATA Interfaces
- 4
- Number of M.2 Interfaces
- 2
- Total Number of Onboard USB Ports
- 8
- Number of Onboard USB 2.0 Ports
- 6
- Number of Onboard USB 3.2 Ports
- 2
- Physical Characteristics
- Form Factor
- Micro ATX
- Width
- 9.6"
- Depth
- 9.6"
