- General Information
- Manufacturer
- Shuttle, Inc
- Manufacturer Website Address
- http://www.us.shuttle.com
- Brand Name
- Shuttle
- Product Line
- XPC slim
- Product Type
- Barebone System
ROBUST 1.3-LITRE SLIM PC SUPPORTS INTEL CORE PROCESSORS WITH SOCKET LGA1700 AND FOUR UHD DISPLAYS
The Shuttle XPC slim Barebone DH770 with H770 chipset houses the performance of Intel's 12th/13th/14th generation Core desktop processors (codenamed Alder Lake-S and Raptor Lake-S [Refresh]) for socket LGA1700 in a compact 1.3-litre format. The DH770 allows for four Ultra HD displays to be operated at the same time via 2x HDMI and 2x DisplayPort. It also offers Dual Intel 2.5G LAN, four USB 3.2 Gen 2 and COM ports. The slim metal chassis comes with a VESA mount included, provides versatile connectivity and reliable operation in environments with ambient temperatures of up to 50 °C. This platform is targeted at professional applications such as Digital Signage, POS, POI, gambling machines, office, healthcare and industry.
- Processor
- Processor Socket
- Socket LGA-1700
- Processor Supported
- Celeron
- Core i3
- Core i5
- Core i7
- Core i9
- Pentium Gold
- 64-bit Processing
- Yes
- Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- H770
- Memory
- Maximum Memory Supported
- 64 GB
- Memory Technology
- DDR5 SDRAM
- Memory Standard
- DDR5-5600/PC5-44800
- Total Number of Memory Slots
- 2
- Storage
- Supported Storage Drive Interfaces
- Serial ATA III
- PCI Express 4.0 x4
- Supported Storage Drive Types
- SSD
- HDD
- Controllers
- Controller Type
- Serial ATA/600
- NVMe
- Display & Graphics
- Graphics Controller Model
- UHD Graphics
- Graphics Memory Technology
- DDR5 SDRAM
- Graphics Memory Accessibility
- Shared
- Network & Communication
- Ethernet Technology
- 2.5 Gigabit Ethernet
- I/O Expansions
- Number of Total Expansion Bays
- 1
- Number of 2.5" Bays
- 1
- Number of M.2 Interfaces
- 2
- Interfaces/Ports
- HDMI (Rear)
- Yes
- Total Number of USB Ports
- 8
- Number of USB 3.2 Gen 1 Ports
- 3
- Number of USB 3.2 Gen 2 Ports
- 4
- USB Type-C (Front)
- Yes
- USB Type-C Detail
- 1x USB 3.2 Gen 1 Type C
- Network (RJ-45)
- Yes
- Number of Network (RJ-45) Ports
- 2
- DisplayPort
- Yes
- Operating System
- Operating System Supported
- Windows 11 x64
- Linux
- Windows 10 x64
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Maximum Power Supply Wattage
- 120 W
- Thermal Design Power
- 65 W
- Frequency
- 50 Hz
- 60 Hz
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Form Factor
- Slim PC
- Height
- 1.7"
- Width
- 6.5"
- Depth
- 7.5"
- Weight (Approximate)
- 2.87 lb
- Miscellaneous
- Energy Star
- Yes
