- General Information
- Manufacturer
- Sharp
- Manufacturer Website Address
- http://www.sharp-nec-displays.com/
- Brand Name
- Sharp NEC Display
- Product Type
- Digital Signage Display
With industry leading experience in superior design and customer focus, the 98" NEC V984Q allows for clear, detailed imagery for unobtrusive digital signage. New contemporary and slim mechanical design with focused aesthetics allows for the smooth and stylistic integration into any type of environment while the full metal chassis coupled with real-time temperature sensors and integrated cooling fans maintain the professional quality necessary for commercial environments. With a wide range of the latest connectivity interfaces including HDMI 2.0 x3 and DisplayPort 1.2 x2/daisy chain option, these displays offer the future-proofing necessary for the investment. These displays also include expandability options such as the Open Pluggable Specification (OPS) and Raspberry Pi Compute Module slots for source integration directly into the display. The V984Q series boasts a 500 cd/m² brightness along with a new anti-glare surface that allows for efficient readability when ambient light is present and is ideal for 24/7 signage in Retail, Transportation, Financial and Healthcare environments.
- Stylish and sleek designallows for easy and unobtrusive integration into any environment
- 500 cd/m² brightnesscombined with UHD resolution and new anti-reflective screen surface will capture the attention of the audience while allowing for clear visibility in higher ambient light conditions
- Future proof modular expansionoptions including the ability to integrate Open Pluggable Specification (OPS) or a Raspberry Pi Compute Modules seamlessly into the display
- SpectraView Engineallows for complete color, intensity, gamma or uniformity control for the ultimate imaging performance
- Integrated Media Playerallows for audio, video or image playback via USB or SD card
- Industrial-strength, premium-grade panelwith additional thermal protection, internal temperature sensors with self-diagnostics and fan-based technology, allows for hassle-free 24/7 operation
- Full 3 year commercial warrantyto allow for peace of mind and protection of this investment
- New!NEC MediaPlayeron the SoC powered by Raspberry Pi
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Bezel Width (Bottom)
- 0.63"
- Bezel Width (Top)
- 0.63"
- Bezel Width (Left)
- 0.63"
- Bezel Width (Right)
- 0.63"
- Panel Technology
- Super In-plane Switching (S-IPS) Technology
- Operation Hours
- 24 Hours/7 Days
- Display & Graphics
- Number of Screens
- 1
- Viewable Screen Size
- 98"
- Display Screen Type
- LCD
- Display Resolution
- 3840 x 2160
- Response Time
- 8 ms
- Pixel Pitch
- 22 mil
- Orientation
- Landscape/Portrait
- Video
- Scan Format
- 2160p
- Native Contrast Ratio
- 1,300:1
- Brightness
- 500 Nit
- Network & Communication
- Ethernet
- Yes
- Interfaces/Ports
- USB
- Yes
- HDMI
- Yes
- DisplayPort
- Yes
- Serial
- Yes
- Number of HDMI Inputs
- 3
- Number of DisplayPorts
- 2
- DisplayPort Output
- Yes
- RS-232C Input
- Yes
- Number of HDMI 2.0 Ports
- 3
- Number of DisplayPort 1.2 Ports
- 2
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Environmental Conditions
- Minimum Operating Temperature
- 32°F (0°C)
- Maximum Operating Temperature
- 104°F (40°C)
- Minimum Storage Temperature
- -4°F (-20°C)
- Maximum Storage Temperature
- 140°F (60°C)
- Minimum Operating Humidity
- 20%
- Maximum Operating Humidity
- 80%
- Minimum Storage Humidity
- 10%
- Maximum Storage Humidity
- 90%
- Physical Characteristics
- Mount Type
- Table Mount
- Wall Mountable
- Height
- 49.2"
- Width
- 86.4"
- Depth
- 3.7"
- Weight (Approximate)
- 202.83 lb
- Height with Stand
- 50.63"
- Width with Stand
- 86.37"
- Depth with Stand
- 23.86"
- Housing Material
- Metal
- Miscellaneous
- Package Contents
- 98" Ultra High Definition Professional Display
- Power Cord
- D2.0misplayPort Cable
- 2.0m HDMI Cable
- Wireless Remote Control
- Batteries
- CD-ROM
- Setup anual
- Clamps
- Screws
- SD Card Cover
- Eyebolt Bracket
- Setup Manual
- CD-ROM (Software & Documentation)
- Application/Usage
- Retail
- Transportation
- Healthcare
