- General Information
- Manufacturer
- Opticon Sensors Europe
- Manufacturer Website Address
- http://www.opticon.com
- Brand Name
- Opticon
- Product Type
- Barcode Scanner
- Technical Information
- Connectivity Technology
- Cable
- Scanning Capability
- 1D
- Barcode Symbology Supported
1D:
- JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128 (EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISMN-ISSN, Matrix 2of5, MSI/Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey
Postal code:
- Chinese Post, Korean Postal Authority code
- Light Source
- Laser
- Scan Rate
- 100 scan/s
- Scan Mode
- Trigger
- Depth of Field
Depth of field At PCS 0.9, Code 39:
- 40 - 500 mm / 1.57 - 19.69 in (1.0 mm / 39 mil)
- 20 - 350 mm / 0.79 - 13.78 in (0.5 mm / 20 mil)
- 20 - 200 mm / 0.79 - 7.87 in (0.25 mm / 10 mil)
- 20 - 100 mm / 0.79 - 3.94 in (0.15 mm / 6 mil)
- 30 - 70 mm / 1.18 - 2.76 in (0.127 mm / 5 mil)
- Scan Pattern
- Bi-directional
- Scanning Distance
- 19.69"
- Features
- Notification LED
- Vibration
- Ergonomic Design
- Scan Button
- Number of Keys
- 1
- Reading Angle (Skew)
- 50°
- Reading Angle (Pitch)
- 35°
- Maximum Ambient Light
- 50000 lux
- Drop Specification
- 1.5 m / 5 ft drop onto concrete surface
- Minimum Element Resolution (Code 39)
- 5 mil
- Maximum Element Resolution (Code 39)
- 39 mil
- Interfaces/Ports
- Host Interface
- Serial
- Power Description
- Input Current
- 150 mA
- Environmental Conditions
- Operating Temperature
- 23°F (-5°C) to 122°F (50°C)
- Storage Temperature
- -4°F (-20°C) to 140°F (60°C)
- Humidity (Non-condensing)
- 10% to 90%
- Physical Characteristics
- Form Factor
- Hands-free
- Color Family
- Black
- Product Color
- Black
- Product Material
- Acrylonitrile Butadiene Styrene (ABS)
- Height
- 5.9"
- Width
- 2.2"
- Depth
- 1.2"
- Weight (Approximate)
- 2.12 oz
- Miscellaneous
- Ingress Protection (IP) Rating
- IP42
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
