- General Information
- Manufacturer
- Microchip Technology Inc.
- Manufacturer Website Address
- http://www.microchip.com
- Brand Name
- Microchip
- Product Type
- PoE Injector
Microchip's single port PoE midspan provides up to 90 Watts of power over Ethernet and offers a IEEE 802.3bt-compliant solution for remote powering of current as well as emerging high power applications. The PD-9601GC is designed to power PoE compliant devices such as IEEE 802.11ax access points, pan-tilt-zoom (PTZ) and dome cameras, IP videophones, thin clients and other high power Ethernet end terminals requiring up to 90W of power. The midspan is IEEE 802.3bt type 4 and is also backward compatible and safe to use with any IEEE 802.3af/at terminal such as VoIP phones, IP cameras and wireless LAN access points, powering 10/100/1000Base-T devices. With the midspan's plug and-play installation, they are easy and cost-effective to implement leveraging existing Ethernet infrastructure while at the same time providing the assurance of a future-proof network.
- Warranty
- Limited Warranty
- 1 Year
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Maximum Input Current
- 1.35 A
- Minimum Frequency
- 50 Hz
- Maximum Frequency
- 60 Hz
- Maximum Output Power
- 95 W
- Interfaces/Ports
- Input Ports
- 1 x Gigabit Ethernet
- Output Ports
- 1 x Gigabit Ethernet
- Physical Characteristics
- Height
- 1.7"
- Width
- 3.5"
- Length
- 6.6"
- Weight (Approximate)
- 1.46 lb
- Miscellaneous
- Package Contents
- 1-Port, IEEE 802.3bt 90W PoE Midspan
- Power Cord
- Certifications & Standards
- IEEE 802.3bt Type 4
- IEEE 802.3af/at
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
- Country of Origin
- China
