- General Information
- Manufacturer
- Harman International Industries, Inc
- Manufacturer Website Address
- http://www.harman.com
- Brand Name
- JBL Professional
- Product Line
- Professional
- Product Type
- Speaker
The AM5212/95 is a medium power, lightweight, 2-way, full-range loudspeaker system comprised of the JBL Differential Drive® dual voice coil and dual magnetic gap 262H-1 300 mm (12 in) low frequency driver and 2408H-1 high frequency 38 mm (1.5 in) exit, 38 mm (1.5 in) voice-coil compression driver. The large format PT™ Progressive Transition waveguide provides excellent 90° x 50° coverage. The waveguide is rotatable so the loudspeaker system can be used in either the vertical or horizontal orientation. High-slope passive networks minimize band overlap. Well-controlled off-axis response enhances arrayability.
- Warranty
- Limited Warranty
- 5 Year
- Technical Information
- Crossover Type
- 2-way
- RMS Output Power
- 300 W
- PMPO Output Power
- 1200 W
- Woofer Driver Size
- 11.81"
- Tweeter Driver Size
- 1.50"
- Minimum Frequency Response
- 43 Hz
- Maximum Frequency Response
- 18 kHz
- Impedance
- 8 Ohm
- Maximum Crossover Frequency
- 1.40 kHz
- Sound Pressure Level
- 129 dB
- Sensitivity
- 113 dB
- Physical Characteristics
- Product Color
- Black
- Product Material
- Birch Plywood
- Steel
- Form Factor
- Wall Mountable
- Height
- 28.1"
- Width
- 14.6"
- Depth
- 18.03"
- Weight (Approximate)
- 44.53 lb
- Miscellaneous
- Certifications & Standards
- Mil-Std 810
- IP-x3 per IEC529
