Buy CyberPower PR2200RT2UN New Smart App Sinewave UPS Systems

CyberPower PR2200RT2UN New Smart App Sinewave UPS Systems

Part: 1182718

$1,407.00

Availability

In Stock

General Information
- Manufacturer
- CyberPower Systems, Inc
- Manufacturer Website Address
- https://www.cyberpowersystems.com/
- Brand Name
- CyberPower
- Product Series
- New Smart App Sinewave UPS
- Product Condition
- New
- Product Type
- Line-interactive UPS

The PR2200RT2UN is a Smart App Sinewave rack/tower convertible UPS with line-interactive topology, surge protection, and battery backup. CyberPower's Smart App Sinewave series creates a sine wave output devoid of power gaps which could cause unexpected shutdowns of sensitive equipment.

The Smart App Sinewave PR2200RT2UN improves battery life through battery equalization technology and Automatic Voltage Regulation (AVR), which corrects minor power fluctuations without switching to battery power. The enhanced chassis design with an easy-to-access toolless front panel, captive screws for battery panel access, and color-coded rear panel make battery changes and installations simple and fast. The PR2200RT2UN also has an innovative LCD panel that rotates 90°, tilts for a better viewing angle, and provides information on 47 different settings including UPS stats, UPS setup and control management, and testing options.

This model includes pre-installed RMCARD205 network management card for remote management and control via a standard web browser or network management system.

With a $400,000 connected equipment guarantee and a three-year warranty, you can trust CyberPower's commitment to the quality of the PR2200RT2UN.

More from the Manufacturer

Warranty
- Limited Warranty
- 3 Year
- Directly Connected Equipment Guarantee
- $400000 Lifetime

Technical Information
- AVR
- Yes
- Plug/Connector Type
- NEMA L5-30P
- Receptacle Type
- NEMA 5-20R
- Receptacle Detail
- 8 x NEMA 5-20R
- Number of Battery & Surge Outlets
- 8
- Number of Critical Load Outlets
- 4
- Transfer Time
- 4 ms
- Dataline Protection
- RJ-45
- Overload Protection
- Yes
- EMI/RFI Noise Filter
- Yes
- Energy Saving
- GreenPower UPS™ Bypass Technology

Power Description
- Load Capacity (VA)
- 2200 VA
- Input Voltage
- 120 V AC
- Input Voltage Range
- 75 V AC - 155 V AC
- Output Voltage
- 100 V AC
- 110 V AC
- 120 V AC
- Input Frequency
- 63 Hz
- Output Frequency
- 60 Hz
- Waveform Type
- Sine Wave
- Surge Energy Rating
- 2430 J

Management
- Network Management
- SNMP/HTTP Remote Monitoring
- Alarm
- Battery Mode
- Low Battery
- Overload
- Overheat
- Over Charge

Controls/Indicators
- Status Indicators
- - Multifunction LCD Panel
  LED Indicators:
  - Power on
  - Line mode
  - Battery mode
  - Fault
  - Night mode
  - Wiring Fault

Interfaces/Ports
- Serial Port
- Yes
- USB (HID Compliant) Port
- Yes
- EPO Port
- Yes

Battery Information
- DC System Voltage
- 12 V DC
- Number of Batteries
- 4
- Battery Characteristics
- Sealed
- Battery Chemistry
- Lead Acid
- Battery Size
- 12V
- Battery Capacity
- 9000 mAh
- Backup/Run Time (Full Load)
- 3.20 Minute
- Backup/Run Time (Half Load)
- 11.80 Minute
- Typical Battery Recharge Time
- 3 Hour
- Replaceable Battery
- Yes

Environmental Conditions
- Maximum Operating Temperature
- 104°F (40°C)
- Storage Temperature
- 5°F (-15°C) - 113°F (45°C)
- Maximum Operating Elevation
- 10000 ft
- Maximum Storage Elevation
- 50000 ft
- Storage Relative Humidity
- 0% - 95%
- Sound Emission (A-Weighted)
- 52.5 dB(A)
- Thermal Dissipation
- 34 W

Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Form Factor
- Rack/Tower
- Rack Height
- 2U
- Height
- 3.4"
- Width
- 17.1"
- Depth
- 16.2"
- Weight (Approximate)
- 59.80 lb

Miscellaneous
- Additional Information
- - Management software: PowerPanel® Business Edition
  - Active PFC Compatible: Yes
  - Extended Battery Option: No
  - Circuit Breaker: 30A
  - Automatic Voltage Regulation: Double boost, single buck
  - Overload Protection: Internal Circuitry Limiting, Circuit Breaker
  - Rated Power Factor: 1
  - Dry Contacts: Yes
  - Enclosure Construction: Metal
  - Replacement Battery Cartridge Quantity: 1
  - Adjustable Voltage Range: 70 - 155 Vac
  - Plug Style: Straight, Twist Lock
  - Overload Protection: Internal Circuitry Limiting, Circuit Breaker
  - Management Cable: USB Cable, EPO Cable
  - Multifunction LCD Panel: 47 Settings (27 setup and control items + 20 status updates and log menus)
  - Operating Relative Humidity: 0 - 95% (non-condensing)
  - Operating Temperature: 32 °F to 104°F (0°C to 40°C)
- Certifications & Standards
- - UL1778
  - VCCI
  - FCC Class A
- Energy Star
- Yes
- Country of Origin
- Philippines
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
