Deliver reliable unfiltered power to connected equipment with the CyberPower PDU13103 basic 3-Phase PDU. Designed for data centers and other electrically demanding applications, this unit features rugged, industrial-grade metal housing, network-grade outlets and operates in high temperatures up to 140°F (60°C).
The PDU13103 supports a 200V-240V 20A input, includes 42 IEC outlets, and provides a maximum output load of 5.7kW. The CyberPower PDU13103 is protected by a three-year limited warranty.
- General Information
- Manufacturer
- CyberPower Systems, Inc
- Manufacturer Website Address
- https://www.cyberpowersystems.com/
- Brand Name
- CyberPower
- Product Type
- PDU
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- PDU Type
- Basic
- Phase
- Three Phase
- Plug/Connector Type
- NEMA L21-20P
- Receptacle Type
- IEC 60320 C13
- IEC 60320 C19
- Receptacle Detail
- 36 x IEC 60320 C13
- 6 x IEC 60320 C19
- Power Description
- Input Voltage
- 230 V AC
- Input Voltage Range
- 200 V AC - 240 V AC
- Output Voltage
- 200 V AC
- 240 V AC
- Output Voltage Range
- 200 V AC - 240 V AC
- Power Rating (Watt)
- 5700 W
- Input Current
- 20 A
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Mounting Orientation
- Vertical
- Mount Type
- Rack-mountable
- Rack Height
- 0U
- Height
- 70.5"
- Width
- 2.2"
- Depth
- 2.2"
- Weight (Approximate)
- 12.61 lb
- Miscellaneous
- Package Contents
- PDU13103 42-Outlets PDU
- Adjustable Mounting Brackets
- Additional Information
- Physical Dimensions - (WxHxD) (cm) : 5.59 x 179.07 x 5.59 (cm)
- Physical Dimensions - (WxHxD) (in) : 2.2 x 70.5 x 2.2 (in)
- Physical Dimensions - (WxHxD) (mm) : 56 x 1791 x 56 (mm)
- Weight (kg) : 5.72
- Weight (lb) : 12.6
- Shipping Dimensions - (WxHxD) (cm) : 17.53 x 16.0 x 201.42 (cm)
- Shipping - Dimensions (WxHxD, in) : 6.9 x 6.3 x 79.3 (in)
- Shipping - Dimensions (WxHxD, mm) : 175.26 x 160.02 x 2014.22 (mm)
- Shipping - Weight (kg) : 9.12
- Shipping - Weight (lb) : 20.1
- Cord Length : 10 ft (3.0 m)
- Derated Input Current : 16 A
- Input Frequency Range : 50 Hz - 60 Hz
- Input Plug Type : NEMA L21-20P
- Maximum Input Current : 20A
- Nominal Input Voltage : 200 - 240 VAC
- Phase : 3 Phase
- Nominal Output Voltage : 200 - 240 VAC
- Outlets - Total : 42
- Outlet Type COMPUTED : 36 - IEC-320 C13
- Overload Protection : None
- Adjustable Mounting Brackets : 1 set
- Color : Black
- Cord Retention Tray/Cord Organizers : Yes
- Form Factors Supported : 0U Vertical Rackmount
- Material of Construction : Metal
- Rack Height : 0U
- Operating Elevation : 0 - 11480 ft (0 - 3499 m)
- Operating Relative Humidity : 0 - 95 % (non-condensing)
- Operating Temperature : 23 - 140 °F (-5 - 60 °C)
- Environmental : RoHS Compliant
- Safety : UL60950-1|FCC Class A|CB
- Product Warranty : 3 Year Limited Warranty
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
