The Cradlepoint NetCloud for Branch with E3000 Series Enterprise Router is suited for fixed offices, healthcare, financial services and retail locations, ideally when combined with need for security services at scale with performance. The all-in-one form factor includes full-featured routing, security, switching with PoE ports and Wi-Fi, making it easy to connect branches to the Internet and critical applications without the need for extra hardware or complicated configurations. And the embedded LTE or 5G modem means that connectivity is always available from day one without waiting for a wired connection.
Ideal for Wireless WAN
For an all wireless WAN, the E3000 Series Router offers Gigabit LTE or 5G NR1 performance, which can support the throughput and service needs of an enterprise branch office or store with the ability to add a second LTE or 5G connection for increased available bandwidth and reliability. For organizations moving to a Wireless WAN, the E3000 Series Router offers the ability to pair with a wired link and use LTE or 5G as a failover connection or a primary connection.
5G Performance Embedded or Optimized
The E3000 Enterprise Branch Router offers 5G performance in two form factors. As a router with embedded 5G, the platform ships standard with the modem as well as a second slot for dual modem capabilities. As a 5G-optimized LTE router, it has the ability to act as a controller for a Cradlepoint 5G Wideband Adapter so that the modem can be placed for optimal signal coverage. The unique capability of Cradlepoint to operate the adapter in captive mode means that the two separate, Ethernet-connected appliances can be managed as a single entity. The two form factors ensure 5G performance in the manner that best suits the deployment needs.
Key Software Capabilities
The Cradlepoint NetCloud for Branch with E3000 Series Router provides everything needed to unlock the power of LTE or 5G at the network edge and connect users and IoT devices to critical applications and services. NetCloud includes routing, VPN, SD-WAN, and security capabilities for robust, enterprise-class performance. Cloud-based management designed for simplification, insights and scale includes group policy definition, reports, troubleshooting, and analytics dashboards. The service includes a warranty for as long as there is an active subscription on the router, online training, live and online support, and all software and firmware updates.
Router Services
The next generation hardware has the processing power to handle demanding routerdelivered services, dynamic routing protocols, and application aware traffic steering, supported with our exclusive NetCloud Essentials + Advanced software package.
Security Services
NetCloud Essentials + Advanced packages include security features and options, such as stateful zone-based firewall, intrusion prevention, and threat protection, to optimize the E3000 Series Router to meet the evolving security needs of distributed environments. Additional security add-ons from leading technology partners make a rich security stack manageable from NetCloud.
Connection Manager
Connection Manager provides the ability to manage all WAN connections types, both wireless and wired, from a single software-defined policy. Our custom-built modem software ensures users establish Wireless WAN connectivity faster while maintaining the highest level of resiliency.
Cloud Services
NetCloud Manager delivers true zero-touch deployment with the ability to define and deliver policy across entire groups of endpoints. Users can create a cloudorchestrated hub and spoke VPN network and gain insights and analytics r
- General Information
- Manufacturer
- ERICSSON
- Manufacturer Website Address
- http://www.cradlepoint.com
- Brand Name
- CradlePoint
- Product Series
- E3000
- Product Type
- Modem/Wireless Router
- Warranty
- Limited Warranty
- Lifetime
- Technical Information
- Wi-Fi Generation
- Wi-Fi 6
- Network Band
- Dual Band
- MU-MIMO Technology
- Yes
- Wireless Specifications
- Broadband Transmission Technology
- Ethernet
- Cellular
- Wireless LAN Standard
- IEEE 802.11ax
- ISM Band
- Yes
- UNII Band
- Yes
- ISM Maximum Frequency
- 2.40 GHz
- UNII Maximum Frequency
- 5 GHz
- Cellular Generation
- 5G
- Cellular Network Supported
- LTE 900
- LTE 700
- LTE 800
- LTE 2300
- LTE 1500
- LTE 600
- LTE 2000
- LTE 2500
- LTE 3500
- LTE 3700
- LTE 5200
- LTE 1900
- LTE 1800
- LTE 1700
- LTE 850
- LTE 2600
- Cellular Data Connectivity Technology
- LTE
- LTE Advanced Pro
- WCDMA
- UMTS
- HSPA+
- 5G NR
- Total Wireless Transmission Speed
- 443.50 MB/s
- Encryption Standard
- WPA3-Personal
- WPA3-ENT
- WPA-PSK
- WPA-PSK2
- WPA2-ENT
- Interfaces/Ports
- Total Number of Network Ports
- 10
- Number of Network (RJ-45) Ports
- 9
- USB
- Yes
- Number of Broadband (RJ-45) Ports
- 1
- USB Standard
- USB 2.0 Type A
- I/O Expansions
- Total Number of Expansion Slots
- 2
- Expansion Slot Type
- SFP+
- Expansion Slot
- Network & Communication
- Ethernet Technology
- 10 Gigabit Ethernet
- VPN Supported
- Yes
- Multi-SIM Supported
- Yes
- Number of SIM Card Supported
- 2
- SIM Size Supported
- Mini
- Physical Characteristics
- Form Factor
- Wall Mountable
- Rack-mountable
- Desktop
- Height
- 1.7"
- Width
- 12.6"
- Depth
- 6.3"
- Weight (Approximate)
- 4.37 lb
- Miscellaneous
- Package Contents
- E3000 Modem/Wireless Router
- Power Supply, 54V, 3.3A, 2x2 Large, 2 Meters
- 4 x Wi-Fi Antenna, Charcoal, Dual-Band 2.4/5 GHz, RPSMA
- Antenna Alignment Tool
- Wall Mount Screw Pack
- Rack Mount Brackets
- Rubber Feet for Desk Mounting
- Certifications & Standards
- UL/cUL
- CB Scheme
- EN 62368-1
- Environmental Compliance
- Waste Electrical and Electronic Equipment Directive (WEEE)
- Restriction of Hazardous Substances (RoHS)
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- TAA Compliant
- Yes
