- General Information
- Manufacturer
- Cisco Systems, Inc
- Manufacturer Website Address
- http://www.cisco.com
- Brand Name
- Cisco
- Product Line
- Catalyst
- Product Series
- 3750-X
- Product Type
- Layer 3 Switch
The Cisco® Catalyst® 3750-X and 3560-X Series Switches are an enterprise-class lines of stackable and standalone switches, respectively. These switches provide high availability, scalability, security, energy efficiency, and ease of operation with innovative features such as Cisco StackPower (available only on the Catalyst 3750-X), IEEE 802.3at Power over Ethernet Plus (PoE+) configurations, optional network modules, redundant power supplies, and Media Access Control Security (MACsec) features. The Cisco Catalyst 3750-X Series with StackWise® Plus technology provides scalability, ease of management and investment protection for the evolving business needs. The Cisco Catalyst 3750-X and 3560-X enhance productivity by enabling applications such as IP telephony, wireless, and video for borderless network experience.
- Warranty
- Limited Warranty
- Lifetime
- Interfaces/Ports
- Total Number of Network Ports
- 48
- Token Ring Port
- No
- LRE Port
- No
- USB
- Yes
- Number of PoE+ (RJ-45) Ports
- 48
- Stack Port
- Yes
- Port/Expansion Slot Details
- 48 x Gigabit Ethernet Network
- Media & Performance
- Ethernet Technology
- Gigabit Ethernet
- Fast Ethernet
- Network Technology
- 10/100/1000Base-T
- 10/100Base-TX
- I/O Expansions
- Total Number of Expansion Slots
- 1.0
- Network & Communication
- Layer Supported
- 3
- Management & Protocols
- Manageable
- Yes
- Management
- QoS
- VLAN
- RMON 1,2,3,9
- Embedded Event Manager
- Command-line interface
- Syslog
- SNMP v1, v2c, v3
- DHCP
- Telnet
- Cisco Network Assistant
- MIB
- CiscoWorks LAN Management Solution
- Memory
- Standard Memory
- 256 MB
- Memory Technology
- DRAM
- Flash Memory
- 64 MB
- Reliability
- MTBF
- 184120 Hour
- Power Description
- PoE (RJ-45) Port
- Yes
- Power Source
- Power Supply
- Redundant Power Supply Supported
- Yes
- Physical Characteristics
- Compatible Rack Unit
- 1U
- Form Factor
- Rack-mountable
- Height
- 1.8"
- Width
- 19.5"
- Depth
- 17.5"
- Weight (Approximate)
- 16.70 lb
- Miscellaneous
- Package Contents
- Catalyst WS-C3750X-48U-S Layer 3 Switch
- 1100W AC Power Supply
- Certifications & Standards
IEEE Standards:
- 802.1s
- 802.1w
- 802.1x
- 802.1x-Rev
- 802.3ad
- 802.1ae
- 802.3af
- 802.3at
- 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports
- 802.1D Spanning Tree Protocol
- 802.1p CoS Prioritization
- 802.1Q VLAN
- 802.3 10BASE-T specification
- 802.3u 100BASE-TX specification
- 802.3ab 1000BASE-T specification
- 802.3z 1000BASE-X specification
EMI and EMC Compliance:
- FCC Part 15 (CFR 47) Class A
- ICES-003 Class A
- EN 55022 Class A
- CISPR 22 Class A
- AS/NZS 3548 Class A
- BSMI Class A (AC input models only)
- VCCI Class A
- EN 55024
- EN300386
- EN 50082-1
- EN 61000-3-2
- EN 61000-3-3
- EN61000-4-2
- EN61000-4-3
- EN61000-4-4
- EN61000-4-5
- EN61000-4-6
- EN 61000-6-1
- UL 60950-1
- CAN/CSA-C22.2 No. 60950-1
- EN 60950-1
- IEC 60950-1
- CCC
- System Requirements
- PC with Windows Vista, XP, or 2000
- Browser (Internet Explorer 5.5, 6.0, 7.0, Firefox 1.5, 2.0, 3.0 or later) with JavaScript enabled
- Straight-through or crossover Category 5 Ethernet cable
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
