- General Information
- Manufacturer
- Black Box Corporation
- Manufacturer Website Address
- http://www.blackbox.com
- Brand Name
- Black Box
- Product Type
- Network Extender
- Warranty
- Limited Warranty
- 1 Year
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Physical Characteristics
- Height
- 0.9"
- Width
- 4.3"
- Depth
- 3.2"
- Miscellaneous
- Additional Information
- Environmental Operating temperature: 32 to 113° F (0 to 45° C);
- Storage temperature: 14 to 158° F (-10 to +70° C);
- Operating humidity: 5-95%, noncondensing
- Approvals CE, RoHS
- Connectors (1) pair ST, (1) RJ-45
- Power External 100-240-VAC power supply, 1.92 watts maximum
- Extends your network up to 220 meters (721 ft.) over 850-nm multimode fiber or a full 2 kilometers (1.2 mi.) over 1300-nm multimode fiber.
- Plug-and-play installation.
- Use as a standalone unit or rackmount in the 16-Slot LinkGain Chassis.
- Link Fault Pass Through (LFP) shuts down a link if the other side fails.
- Auto-sensing 10-/100-Mbps copper ports feature MDI/MDI-X.
- Must be used in pairs.
- Country of Origin
- Taiwan
- TAA Compliant
- Yes
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
