With the incredible sum of its parts
The ROG Strix GeForce RTX™ 4070 SUPER brings a whole new meaning to going with the flow. Inside and out, every element of the card gives the monstrous GPU headroom to breathe freely and achieve ultimate performance. The unleashed reign of the NVIDIA Ada Lovelace architecture is here
NVIDIA Ada Lovelace Architecture | Designed to Give You Superpowers
New Streaming Multiprocessors
- Up to 2X performance and power efficiency
Fourth-Gen Tensor Cores
- Up to 4X performance with DLSS 3 vs. brute-force rendering
Third-Gen RT Cores
- Up to 2X ray tracing performance
Axial-tech Upgrades| A Fresh Spin
Bigger and better. Axial-tech fans spin on dual-ball bearings and have been scaled up to propel 31% more air through the card, setting the stage for lower temperatures, less noise, and higher performance
Reverse Rotation and 0dB Technology | Orchestrated Chill
The two side fans spin counterclockwise to minimize turbulence and maximize air dispersion through the heatsink. All three fans come to a standstill when GPU temps are below 50 Celsius, letting you play less-demanding games or perform light tasks in relative silence. Fans start up again when temps are over 55°C, referencing a speed curve that balances performance and acoustics for work or play
3.12-slot Design | Through Thick and Fin
The custom sink is generously sized and structured to soak up heat from the GeForce RTX 4070 SUPER GPU so that it can be efficiently whisked away by the three Axial-tech fans
Premium Power Delivery | 1st Responder
Digital power control, an array of high-current power stages, and a lineup of 15K caps ensure massive reserves to reliably push performance boundaries
Metal Exoskeleton | Ultra-rigid
A high-quality diecast frame, shroud, and backplate tightly brace the PCB and strategically steer airflow
FanConnect II Hook up
Two PWM FanConnect headers provide additional DIY flexibility. Chassis fans can be directly attached to the card and tuned with a curve that is based on CPU and GPU temperatures, delivering extra intake or exhaust for demanding 3D tasks.
Reinforcements | Additional Perks
A GPU bracket provides extra stability to the critical connection between die and heat spreader. The rear I/O bracket is made from stainless steel to prevent corrosion in humid climates and provide a more resilient mount. A conveniently placed Dual Bios switch allows quick selection between "performance" and "quiet" speed profiles for the Axial-tech fans
Power Sensing | Quick Diagnosis
Know if your PSU is worthy. ROG Strix GeForce RTX 4070 SUPER graphics cards feature a high-speed circuit that constantly monitors input power from the PSU and utilizes conveniently placed LEDs to indicate voltage regulation issues and cable connection problems
- General Information
- Manufacturer
- ASUS Computer International
- Manufacturer Website Address
- http://usa.asus.com
- Brand Name
- Asus ROG
- Product Line
- Strix
- Product Type
- Graphic Card
- Warranty
- Limited Warranty
- 36 Month
- Technical Information
- API Supported
- OpenGL 4.6
- Number of Monitors Supported
- 4
- Features
- Triple-fan Cooler
- Maximum Digital Display Resolution
- 7680 x 4320
- CUDA Cores
- 7168
- AI-powered
- Yes
- Processor & Chipset
- Chipset Manufacturer
- NVIDIA
- Chipset Line
- GeForce
- Chipset Series
- RTX
- Chipset Model
- RTX 4070 SUPER
- GPU Boost Clock
- 2.51 GHz
- Memory
- Standard Memory
- 12 GB
- Memory Technology
- GDDR6X
- Bus Width
- 192 bit
- Interfaces/Ports
- Host Interface
- PCI Express 4.0
- DisplayPort
- Yes
- Number of DisplayPort Outputs
- 3
- HDMI
- Yes
- Number of HDMI Outputs
- 2
- Power Description
- Power Supply Wattage
- 750 W
- Power Connector
- 1x 16-pin
- Physical Characteristics
- Slot Space Required
- Triple
- Form Factor
- Plug-in Card
- Cooler Type
- Fan Cooler
- Height
- 2.5"
- Width
- 5.9"
- Length
- 13.3"
- Miscellaneous
- Package Contents
- ROG Strix GeForce RTX 4070 SUPER 12GB GDDR6X Graphic Card
- 1 x Collection Card
- 1 x Speedsetup Manual
- 1 x Thank you Card
- 1 x ROG Velcro Hook & Loop
- 1 x ROG Graphics card holder
- 1 x Adapter cable (1 to 2)
- Platform Supported
- PC
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
