- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com
- Brand Name
- APC by Schneider Electric
- Product Line
- Smart-UPS
- Product Type
- Line-interactive UPS
This APC Smart-UPS is designed for IT managers or network administrators to maintain business uptime, data transfer and continuity during prolonged power outages. The 2880VA line interactive 4U rack/tower UPS provides pure sine wave power to support critical electronics during power disruptions. The SMX comes with NEMA L5-30P input, 6x NEMA 5-15R, 3x NEMA 5-20R and 1x NEMA L5-30R outlets. The UPS has a preinstalled Network Management Card for UPS network-based monitoring and management. The Smart-UPS comes with PowerChute Network Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. This uninterrupted power supply can connect to EcoStruxure IT or third-party centralized management platforms. The SMX UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. This is compatible with dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications. The Smart-UPS comes with a pair of tower-mounting stabilizing feet and rack-mounting brackets. It comes with APC temperature sensor AP9335T for monitoring temperature. The 3 switchable outlet groups allow more granular management of the power supplied to your devices. The Emergency Power Off feature enables the UPS to remotely shutdown during emergencies. The UPS is TAA Complaint.
- Warranty
- Limited Warranty
- 3 Year
- Additional Warranty Information
- 3 years repair or replace (excluding battery) and 2 years for battery, optional extended warranties available, optional on-site warranties available
- Directly Connected Equipment Guarantee
- $150000 Lifetime
- Technical Information
- Plug/Connector Type
- NEMA L5-30P
- Receptacle Type
- NEMA L5-30P
- Receptacle Detail
- 1 x NEMA L5-30R
- 3 x NEMA 5-20R
- 6 x NEMA 5-15R
- Number of Battery & Surge Outlets
- 10
- Cord Length
- 8 ft
- Application/Usage
- Server
- POS Terminal
- Router
- Switch
- Network Hub
- Network Device
- Security System
- Storage Device
- Power Description
- Load Capacity (VA)
- 2880 VA
- Load Capacity (Watt)
- 2700 W
- Input Voltage
- 120 V
- Input Voltage Range
- 70 V AC - 153 V AC
- Input Current
- 15 A
- Output Voltage
- 120 V AC
- Waveform Type
- Sine Wave
- Surge Energy Rating
- 540 J
- Battery Information
- Battery Chemistry
- Lead Acid
- Backup/Run Time (Full Load)
- 6.30 Minute
- Typical Battery Recharge Time
- 3 Hour
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Height
- 17"
- Width
- 7"
- Depth
- 19"
- Rack Height
- 4U
- Form Factor
- Rack-mountable
- Mounting Preference
- Lower
- Mounting Location
- Front
- Weight (Approximate)
- 85.19 lb
- Miscellaneous
- Package Contents
- Smart-UPS SMX3000LVNCUS 2.88kVA Tower/Rack Convertible UPS
- CD with software
- Documentation CD
- Installation guide
- Rack mounting brackets
- Rack mounting hardware
- Rack mounting support rails
- Removable support feet
- Smart UPS signalling RS-232 cable
- USB cable
- Web/SNMP management card
- Certifications & Standards
- BSMI|CSA|NOM|TAA compliance|TÜV|VCCI Class A
- Energy Star
- Yes
- Green Premium
- Yes
- Optimized Energy Efficiency
- Yes
- Product Take Back Program
- Yes
- Mercury Free
- Yes
- RoHS Exemption Information
- https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=SMX3000LVNCUS_ROHS_DECLARATION&p_FileName=SMX3000LVNCUSKIT_ROHS_DECLARATION_US.pdf
- REACH Declaration URL
- https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=490326965&lang=en-us
- EU RoHS Declaration URL
- https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=490326965&lang=en-us
- Environmental Profile Availability
- https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1612029_EN
- End of Life Manual Availability
- https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1612029_EN
- REACH free of SVHC
- No
- TAA Compliant
- Yes
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
